Where to Put the Fridge and Power Station in a Tesla Camper Setup
A Tesla camping setup gets easier the moment you stop treating the trunk as one big box. The question isn't what gear to bring. It's where each item lives, so you can still sleep flat, reach what matters, and not unpack half the car to make coffee.
Two items cause most of the layout stress: the fridge and the power station. Here are the numbers that decide where each one goes.
The numbers that decide your layout
| What | Figure | Why it matters |
|---|---|---|
| 40–45 L compressor fridge | ~400 Wh per day (typical range 240–600 Wh) | This is the single biggest draw in the car after climate. |
| Same fridge at 21 °C ambient | ~1.5 A/h at 12 V | Cool day, easy life. |
| Same fridge at 35 °C ambient | 3–4 A/h | Roughly double. A parked car in summer hits this easily. |
| 1000 Wh power station | 1–2 days of fridge | Allow a 20–30% buffer for inverter and temperature losses. |
| Camp Mode, our own test | 24% of battery over 9 hours at −7 °C | Climate is the car's job, not the power station's. |
Read that table once and the layout writes itself: the fridge needs a cold, ventilated, low place you rarely touch. The power station needs to be within arm's reach, because you'll handle it several times a day.
Rule one: the bed zone stays for sleeping
If you sleep in the car, the mattress is not storage. No food boxes, no charging bricks, no cables crossing where your legs go. The layout that works:
- cold storage low and tucked away
- power accessible but not underfoot
- small essentials near the doors or in the drawer
- sleeping surface clean
Fridge: the sub-trunk
In a Model Y the sub-trunk is the cleanest place for a compact fridge. Weight stays low, the main trunk stays free, and cold food doesn't take over the space you sit, cook and sleep in.
The Teraglide PRO lift system keeps that space reachable with the platform installed and the bed made — which is the difference between a fridge you use and a fridge you resent.
Ventilation is not optional
A compressor fridge rejects heat, and a fridge that can't breathe runs longer and eats the numbers in the table above. Practically:
- keep the vent side clear — no soft bags, towels or bedding against it
- don't wedge it in like a brick
- check the manual for your model's required clearance
If your setup needs the floor raised slightly for airflow, plan that before the first trip rather than after you notice poor cooling on day two.
Power station: close, not buried
You'll reach for the power station far more often than the fridge — phone, light, camera battery, taking it outside to cook. So it belongs where you can get it without unpacking.
- Near the drawer or trunk opening. Best option if you use it daily. Shorter cables, easy to lift out.
- Sub-trunk only if it's backup. Fine for "leave it and forget it", poor for anything hourly.
- Never loose beside the mattress. Convenient until you want to stretch out at 1 a.m.
Sizing it: at ~400 Wh a day for the fridge alone, a 1000 Wh unit covers a weekend with a margin, and roughly a day and a half in hot weather. Anything longer and you're planning a recharge, not a bigger battery.
Let the car do the climate
Camp Mode holds cabin temperature overnight and keeps the windows clear — 24% of the battery over nine hours at −7 °C in our own test. That's the car's job. Leave the power station for gear, and you keep both budgets simple.
More on overnight airflow, condensation and battery drain: how to ventilate your car overnight.
The layout that works for most weekends
| Zone | What lives there |
|---|---|
| Sub-trunk | Compact fridge, cold food, drinks, breakfast supplies |
| Drawer | Stove, mugs, cutlery, snacks, daily small items |
| Near the trunk opening | Power station, charging cables, headlamps |
| Bed surface | Mattress and bedding. Nothing else. |
The PRO drawer is rated to 50 kg and the bed base to 180 kg, so the constraint on this layout is space, not strength.
Why layout beats gear
Most first setups fail for small reasons, not big ones. Not because the car is too small — because the layout creates friction all day. You stop for lunch and can't reach the fridge. You go to bed with cables across the mattress. You wake up and unload half the trunk to boil water.
A platform fixes half of it by giving you flat sleep with storage underneath. The layout finishes the job by deciding what belongs where.
Want a setup that still works as an everyday car? Read why a no-modification platform suits daily drivers.
FAQ
How much power does a 12V fridge use per day?
A 40–45 L compressor fridge averages around 400 Wh a day, with a typical range of 240–600 Wh depending on ambient temperature and insulation.
How long will a 1000 Wh power station run a fridge?
Roughly 1–2 days. Allow a 20–30% buffer for inverter and temperature losses, and expect the shorter figure in hot weather.
Where should the fridge go in a Tesla Model Y?
The sub-trunk. It keeps weight low, frees the main trunk, and with a lift-up platform it stays reachable with the bed made.
Does a fridge need ventilation in a car?
Yes. Keep the vent side clear of bags and bedding. A fridge that can't reject heat runs longer and uses noticeably more power.
Should the power station run the heating too?
In an EV, no — Camp Mode handles cabin climate directly from the car battery. Our test used 24% over nine hours at −7 °C. Leave the power station for gear.
Final thought
If you change one thing in your setup, change this: put the fridge where it stays cold and out of the way, and the power station where you can actually reach it.
- Fridge — sub-trunk
- Power station — near the trunk opening or drawer
- Bed — left for sleep
Start with the Teraglide PRO for a Model Y, or compare all Teraglide platforms to see what fits your vehicle.
References: Tesla climate controls · Tesla accessory power · Portable fridge ventilation guidance
